15% Off

Elma Ultrasonic EASY 20H - 1.75L

Stock Code:
42-126-020
$1,021.06 ex gst
$829.62 ex gst

Stock Locations

Description


efficient 37 kHz ultrasonic high-performance transducers

cleaning tank made of cavitation-resistant stainless steel

user-friendly and clearly arranged operating panel; sealed against liquid intrusion to protect the electronics

LED display for ultrasonic function

rotary switch for easy preselection of the cleaning time

continuous operating or short-term operation between 1 and 30 minutes

permanent sweep function for optimized sound field distribution through frequency modulation

dry-run protected heating

temperature selectable by rotary switch; from 30°C to 80°C in increments of 5°C (for H units)

LED display for heating operation (for H units)

detachable power cord with IEC plug

selectable temperature threshold with alarm

automatic safety shutdown after 8 hours of continuous operation

automatic safety shutdown at a bath temperature of 90 °C

« Pulse« function



Mains voltage (VAC) 220-240 V

Ultrasonic frequency (kHz) 37

Total power consumption EASY 20 (W) 35

Total power consumption EASY 20 H (W) 155

Effective ultrasonic power (W) 35

Max. ultrasonic peak performance** (W) 280

Heat output (for H units) (W) 120

Device external dimensions W / D / H (mm) 176 / 176 / 219

Tank external dimensions W / D / H (mm) 137 / 123 / 99

Basket internal dimensions W / D / H (mm) 112 / 103 / 50

Max. filling volume (litres) 1.75

Weight (kg) 2.1

Tank material stainless steel

Casing material stainless steel

Sound pressure level (LpAU) (with cover) <70 db

Protection class IP 20

2 year limted warranty

Made in Germany
